車載控制器TCXO晶振1XTW20000CCA，晶振是電子產品都得依賴的一款電子器件,它是通常應用到一些高端電子產品當中。削波正弦波形是TCXO晶振最受歡迎的輸出選項,這是為什么呢,主要原因有兩點.其一是低功耗,改善了熱特性以及更好的老化和頻率穩定性能;其二則是比CMOS輸出更好的相位噪聲性能.也就是說石英晶振在采用削波正玄波作為輸出方式之后會極大的減少諧波分量的數量,使得晶振產品具備低相位噪聲的性能.車載控制器TCXO晶振1XTW20000CCA
| 品牌 | 原廠編碼 | 溫補晶體振蕩器 | 尺寸 | 頻率 |
| KDS晶振 | 1XXD38400HCA | DSB211SCM | 2016 | 38.400MHz |
| KDS晶振 | 1XXD26000CAL | DSB211SDA | 2016 | 26.000MHz |
| KDS晶振 | 1XXD16367JAA | DSB211SDM | 2016 | 16.367667MHZ |
| KDS晶振 | 1XXD16368JBA | DSB211SDM | 2016 | 16.368MHz |
| KDS晶振 | 1XXD16369JDA | DSB211SDM | 2016 | 16.369MHz |
| KDS晶振 | 1XXD26000JMB | DSB211SDM | 2016 | 26.000MHz |
| KDS晶振 | 1XXD26000JHC | DSB211SDM | 2016 | 26.000MHz |
| KDS晶振 | 1XXD16367MAA | DSB211SDN | 2016 | 16.367M |
| KDS晶振 | ZC12456 | DSB211SDN | 2016 | 16.320MHz |
| KDS晶振 | 1XXD24000MBA | DSB211SDN | 2016 | 24.000MHz |
| KDS晶振 | 1XXD32000PBA | DSB211SDN | 2016 | 32.000M |
| KDS晶振 | 1XXD26000MAA | DSB211SDN | 2016 | 26.000MHz |
| KDS晶振 | 1XXD26000MBC | DSB211SDN | 2016 | 26.000MHz |
| KDS晶振 | 1XXB52000HAA | DSB221SCM | 2016 | 52.000MHZ |
| KDS晶振 | 1XXB16367CCA | DSB221SDA | 2520 | 16.367667MHZ |
| KDS晶振 | 1XXB16369CAA | DSB221SDA | 2520 | 16.369MHz |
| KDS晶振 | 1XXB40000CCA | DSB221SDA | 2520 | 40.000MHZ |
| KDS晶振 | 1XXB26000CTB | DSB221SDA | 2520 | 26.000MHz |
| KDS晶振 | 1XXB16368JFA | DSB221SDM | 2520 | 16.368MHz |
| KDS晶振 | 1XXB38400JEA | DSB221SDM | 2520 | 38.400MHz |
| KDS晶振 | 1XXB16367MAA | DSB221SDN | 2520 | 16.367M |
| KDS晶振 | 1XXB16369JFA | DSB221SDN | 2520 | 16.369MHz |
| KDS晶振 | 1XXB38400MCB | DSB221SDN | 2520 | 38.4M |
| KDS晶振 | 1XXB24000MEA | DSB221SDN | 2520 | 24.000MHz |
| KDS晶振 | 7EE05200A02 | DSB221SDN | 2520 | 52MHZ |
| KDS晶振 | 1XXB16368MAA | DSB221SDN | 2520 | 16.368MHz |
| KDS晶振 | 1XXB25600MAA | DSB221SDN | 2520 | 25.6M |
| KDS晶振 | 1XXB26000MAA | DSB221SDN | 2520 | 26.000MHz |
| KDS晶振 | 1XXB19200MDA | DSB221SDN | 2520 | 19.200MHz |
| KDS晶振 | 1XXD38400MFA | DSB221SDN | 2520 | 38.400MHz |
| KDS晶振 | 1XXB38400MAA | DSB221SDN | 2520 | 38.400MHZ |
| KDS晶振 | 1XXB12288EAA | DSB221SJ | 2520 | 12.288MHz |
| KDS晶振 | 1XTW16367ADA | DSB321SCA | 3225 | 16.367667MHZ |
| KDS晶振 | 1XTW20000AAA | DSB321SCA | 3225 | 20.000MHz |
| KDS晶振 | 1XTW16368FEA | DSB321SCL | 3225 | 16.368MHz |
| KDS晶振 | 1XTW12288FAB | DSB321SCL | 3225 | 12.288MHz |
| KDS貼片晶振 | 1XTW14745FBA | DSB321SCL | 3225 | 14.7456MHZ |
| KDS晶振 | 1XTW30000FCA | DSB321SCL | 3225 | 30.000MHZ |
| KDS晶振 | 1XTW40000FBA | DSB321SCL | 3225 | 40.000MHZ |
| KDS晶振 | 1XTW52000FAA | DSB321SCL | 3225 | 52.000MHZ |
| KDS晶振 | 1XTW10000CAB | DSB321SDA | 3225 | 10.000MHz |
| KDS晶振 | 1XTW16367CFB | DSB321SDA | 3225 | 16.367667MHZ |
| KDS晶振 | 1XTW20000CCA | DSB321SDA | 3225 | 20.000MHz |
| KDS晶振 | 1XTW29491FAA | DSB321SDA | 3225 | 29.4912MHZ |
| KDS晶振 | 1XTW26000CGA | DSB321SDA | 3225 | 26.000MHz |
| KDS晶振 | 1XTW16367CF | DSB321SDA | 3225 | 16.367667MHz |
| KDS晶振 | 1XTW19200JBA | DSB321SDM | 3225 | 19.200MHz |
| KDS晶振 | 1XTW25000JAA | DSB321SDM | 3225 | 25.000MHz |
| KDS晶振 | 1XTW19200MCA | DSB321SDN | 3225 | 19.200MHz |
| KDS晶振 | 1XTW16367MAA | DSB321SDN | 3225 | 16.367667MHZ |
| KDS晶振 | 1XTW16368MAA | DSB321SDN | 3225 | 16.368MHz |
| KDS晶振 | 1XTW16369MAA | DSB321SDN | 3225 | 16.369MHz |
| KDS晶振 | 1XTW26000MAA | DSB321SDN | 3225溫補晶振 | 26.000MHz |
| KDS晶振 | 1XTR25000VAA | DSB535SD | 5032 | 25.000MHz |
| KDS晶振 | 1XZA032768AD9 | DSK321STD | 3225 | 32.768KHz |
| KDS晶振 | 1XZA032768AD19 | DSK321STD | 3225 | 32.768KHz |
車載控制器TCXO晶振1XTW20000CCA，溫補晶振即溫度補償晶體振蕩器（TCXO晶振），本身具有溫度補償作用，是通過附加的溫度補償電路使由周圍溫度變化產生的振蕩頻率變化量削減的一種石英晶體振蕩器，高低溫度穩定性:頻率精度0.5PPM~2.0PPM,常用頻率:26M,33.6M,38.4M,40M.因產品性能穩定,精度高等優勢,被廣泛應用到一些比較高端的數碼通訊產品領域,GPS全球定位系統,智能手機,WiMAX和無線通信等產品,符合RoHS/無鉛.車載控制器TCXO晶振1XTW20000CCA
